The Hager ADC910T is a Residual Current Breaker with Overcurrent Protection.
This new style was manufactured to meet new wiring regulations to minimise injuries related to electric shock. This new slimline design is also commonly referred to as a single pole combo and was developed to maximise space in domestic switchboards and load centres. The Hager 10 Amp Rcbo also saves time and money on installation. As both line and load terminals are non-sensitive, rewiring is not required if replacing an alternative brand.
This is a single-pole MCB/RCD combination – It only takes up the space of 1 module in a switchboard or subboard. Extra Space when Wiring as compared to the ADC3XXT range: Reduced height allows more wiring space in the enclosure (up to 20% extra in Golf Enclosures)
Features:
- Rated current (In): 10A
- Rated voltage (Un): 240V
- Rated residual operating current (I n) 30mA
- Curve Type C
- Operating characteristic Type A
- Rated Frequency 50Hz
- Rated short-circuit capacity (Icn) 6kA
- IP rating or Protection degree IP2x terminals
- Standard AS/NZS 61009
- Electrically Bi-directional
- Switched Neutral
- Insulation Resistance test is faster to perform
- Built in fault trip indicator
- It’s reduced size makes it a perfect replacement for an MCB
