22-3B-103F100D Compatible Waeco / Dometic Long Thermistor — Sensor Only
This listing is the long compatible thermistor sensor for selected Waeco and Dometic portable fridges. Heatsink compound is not included; it is required for correct installation. For the version supplied with paste and applicator, use the complete thermistor-and-paste kit.
Part-number references
22-3B-103F100D, 22-3B-103F08A and 4450001983.
Fitment
This long thermistor is used across selected CF, CDF and CFX fridge families. It can replace the short thermistor where the exact appliance configuration has been confirmed. That substitution does not make it a universal fit for every fridge in a model family.
Common model-family references include CF18, CF25, CF35, CF40, CF50, CF60, CDF35, CDF40, CDF45, CFX28, CFX35, CFX40, CFX50, CFX65, CFX65DZ, CFX35W, CFX40W, CFX50W, CFX65W, CFX75DZW and CFX100W. CFX95 and CFX95DZ configurations need individual PNC/model confirmation because sensor arrangements can vary.
Before ordering
Confirm the full model/PNC from the fridge rating plate and compare the original sensor length and connection. Some dual-zone configurations may use more than one sensor. If you are unsure, send us the rating-plate details and a photo of the existing thermistor before ordering.
